LED Panel Light 36W 48W Office Square LED Ceiling Panel Light

Product Categories

Shenzhen DSF Science&Technology Co., Ltd.

Contact Now

Brand Name : DSF

Model Number : DSF-PL1

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : T/T Paypal

Supply Ability : 3000pcs/month

Delivery Time : 2 weeks

Product No : PL1

Power : 36W, 48W,

Dimension : 620*620*10mm

High Light : flat square led light, surface mount led panel fixture

Power Factor : ≥0.98

CRI : ≥80

Contact Now

FEATURES

Ultra-thin design, saving 70% of energy, luminous efficiency up to 120LM/W, light uniformity.
The five-year period of use.
Wide voltage AC100-240V
Quick start, no flicker, without noise
The latest high efficiency constant current driver
Professional circuit design, each group of LED work separately so that can avoid a single bad light affect the overall light effect.
Anti-radio interference, in line with CE requirements.
Lead-free, green, in line with ROHS requirements.
No RF interference

Application Scope

LED Panel Light 36W 48W Office Square LED Ceiling Panel Light

Technical Parameter

No	Item	Parameter
1	Size	62062010mm
2	Input Voltage	AC 100-240V
3	Working Voltage	≤38V
4	Power	36W/48W
5	Luminous	≥4000 lm
6	Power Efficiency	≥100 lm/w
7	Color	Warm/Natural/Cool White
8	Color Temp	WW / Warm White 2800-3200K NW / Natural White 4000-4500K CW / Cool White 6000-6500K
9	CRI	≥80Ra
10	LED Qty	192 PCS
11	LED Type	2835(0.5W)
12	Life Span	50000 Hours
13	Operating Temp	-20ºC — 50ºC
14	Storage Temp	-20ºC — 60ºC
15	Net Weight	3.65KG
16	Gross Weight	4.3KG
17	IP	IP 40
